TGV-20
TGV-20 Two Piece Full Bore Ball Valve
In ball valves, the main element is a sphere with a hole in the middle. At 90 ° rotation of this sphere, it is switched from fully open to fully closed position. Ball valves are used primarily in places that are very open and close or where quick opening and closing is desired.
Advantages are low pressure losses, easy opening and closing, good sealing, light weight and small footprint.
Sealing ; It consists of two stages as sphere sealing and shaft sealing.
Ayvaz TGV-20 Two-Piece Full Bore Ball Valves are important control elements that provide on-off and flow control. Ball valves due to their structure and flow patternvalves with the least pressure loss. Particularly with Ayvaz TGV-20 Two-Piece Full Bore Ball Valves, an basınç equivalent pressure loss ına is provided to the pressure loss occurring in the same diameter pipe.
It has an upper flange in accordance with ISO 5211 and is suitable for the actuator assembly.
SPECIFICATION
Material Structure:
Body : GG25 Cast Iron
Ball : AISI316 Stainless Steel
Connections : Flanged
Nominal Diameter : DN40 (1 1/2 ”) – DN250 (10”)
Pressure Values : Max.
Temperature range up to 16 bar : -10ºC to 120ºC depending on the material structure.
Applications:
- Heating
- cooling lines
- Food plants
- Chemical sector
- Ship constructions
- Papermills
